9.5.3 Menu 2 Setpoints UR 141 TE
SETPOINTS POS: XXXXX
1 Cooling Move to menu 2-1;
Special case: When one-zone (tandem) operation is set (Menu 6-1) and setpoint
toggle is deactivated (Menu 3-3), Continue to 2-1-1
2 Defrost Move to menu 2-2;
Special case: When one-zone (tandem) operation is set (Menu 6-1) and setpoint
toggle is deactivated (Menu 3-3), Continue to 2-2-1
3 Fans Move to menu 2-3;
Special case: When one-zone (tandem) operation is set (Menu 6-1) and setpoint
toggle is deactivated (Menu 3-3), Continue to 2-3-1
4 Alarm Move to menu 2-4;
Special case: When one-zone (tandem) operation is set (Menu 6-1) and setpoint
toggle is deactivated (Menu 3-3), Continue to 2-4-1
5 Frame Heater Move to menu 2-5
Menu 2-1 Cooling
COOLING POS: XXXXX
1 Zone 1 Move to menu 2-1-1
2 Zone 2 Move to menu 2-1-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-1-3; not shown when setpoint toggle is deactivated (Menu 3-3)
3 Zone 2T Toggle Move to menu 2-1-4; shown only when two-zone operation is set (Menu 6-1) and when
setpoint toggle is not deactivated (Menu 3-3)
Menu 2-1-1 Zone 1
COOLING 1 POS: XXXXX Entry Default
Setpoint R4.1 XXX °C Room air temperature setpoint --, -45..40 -20 °C
Hystersis R4.1 X K Room air temperature hysteresis setpoint; shown only
when on-off control is set (Menu 2-1-1)
1..10 2 K
Ht. Cir. Setp. Heating circuit control setpoint; shown only when
single-zone operation is set (Menu 6-1)
--, -45..40 -20 °C
Ht. Cir. Hyst. Heating circuit control hysteresis setpoint; shown only
when single-zone operation is set (Menu 6-1)
1..10 2 K
Superheat XXX K Superheat setpoint Zone 1 0..20 6 K
Min. SH XX K Minimum superheat setpoint, below which cooling relay
switches off in Zone 1. I-sum (not I-part) is set to zero
when the Reset I-Sum parameter is set to ON.
0..10 2 K
Two pos.ctrl XXX Switch between on-off control (ON) and continuous
control (OFF)
↑,↓
(ON/OFF)
OFF
MOP-point XXX °C Starting setpoint for MOP mode --, -50..50 -- °C
