ECKELMANN Case Controller UA 4 E Series - Menu 1 Actual Values UA 141 E

Firmware V3.13
21.04.2021
272/466
•
9.3.2 Menu 1 Actual Values UA 141 E
ACT VALUES POS: XXXXX
1 Temp. Sensor Move to menu 1-1
2 Cooling Zone 1 Move to menu 1-2
3 Defrost Zone 1 Move to menu 1-3
4 Evap. fans Move to menu 1-4
5 Alarm Move to menu 1-5
6 Frame Heater Move to menu 1-6
7 Cooling Zone 2 Move to menu 1-7: Menu item is shown only when two-zone operation is set
(Menu 6-1).
8 Defrost Zone 2 Move to menu 1-8: Menu item is shown only when two-zone operation is set
(Menu 6-1).
Menu 1-1 Temp. Sensor
TEMPERATUR XXXXX
Temp. R2.1 XXX °C Displays current supply air temperature Input Z11/Z12
Temp. R4.1 XXX °C Displays current return air temperature Input Z21/Z22
Temp. R1.1 XXX °C Displays current evaporator defrost termination temperature Input Z31/Z32
Temp. R5.1 XXX °C Displays current evaporator inlet temperature Input Z41/Z42
Temp. R6.1 XXX °C Displays current evaporator outlet temperature Input Z51/Z52
Temp. R2.2 XXX °C Displays current supply air temperature Input Z61/Z62
Temp. R4.2 XXX °C Displays current return air temperature Input Z71/Z72
Temp. R1.2 XXX °C Displays current evaporator defrost termination temperature Input Z81/Z82
Temp. R5.2 XXX °C Displays current evaporator inlet temperature Input Z91/Z92
Temp. R6.2 XXX °C Displays current evaporator outlet temperature Input Z01/Z02
to VS corr. XXX °C Displays current corrected suction pressure temperature on VS pack controller
(assigned
by Pack No.)
t0 locale Z1 xxx °C
Displays current t
0
temperature zone 1
1)
t0 locale Z2 xxx °C
Displays current t
0
temperature zone 2
1) 2)
tc xxx °C
Displays current t
c
temperature
1) 2)
Humidite xx %
Displays current, relative humidity
1) 2)
