ECKELMANN Case Controller UA 4 E Series - Contr. Type UA 141 E - Menu Tree

Firmware V3.13
21.04.2021
268/466
9.3 Contr. Type UA 141 E - Menu tree
DIP switch S3 UA 141 E
1: ON
2: ON
3: OFF
4: ON/OFF = Master-/Salve-Modus ON/OFF
5: OFF
6: ON/OFF = Funktionsweise der Analogausgänge 0..10 V
7..8: OFF
9: ON
Main Menu Submenu 1 Submenu 2 Menu No. Menu Name
Actual Values 1 Actual Values
Temperatue Sensors 1-1 TEMPERATUR
Cooling Zone 1 1-2 COOLING 1
Defrost Zone 1 1-3 DEFROST 1
–
Alarm 1-5 ALARM
Pane Heater 1-6 PANE HTR
Cooling Zone 2 1-7 Cooling Zone 2
Defrost Zone 2 1-8 DEFROST 2
Setpoints 2 SETPOINTS
Cooling 2-1 COOLING
Zone 1 2-1-1 COOLING 1
Zone 2 2-1-2 COOLING 2
Zone 1T Toggle 2-1-3 COOLING 1A
Zone 2T Toggle 2-1-4 COOLING 2A
Defrost 2-2 DEFROST
Zone 1 2-2-1 DEFROST 1
Zone 2 2-2-2 DEFROST 2
Zone 1 Umschaltung 2-2-3 DEFROST 1A
Zone 2 Umschaltung 2-2-4 DEFROST 2A
—
