ECKELMANN Case Controller UA 4 E Series - Page 165

Firmware V3.13
21.04.2021
165/466
Controller type D42/D41 D32/D31 D22/D21 D12/D11
Case controller
UA 121 E
UA 131 E
UA 131 E LS
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Manual shutdown All
1)
or
Manual shutdown Z1 /
Manual shutdown Z2
Toggle setpoint
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Defrost
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Case controller
UA 141 E
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Pane button
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Toggle setpoint
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Shutdown button
Defrost
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Cold room controller
UR 141 NE
UR 141 TE
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Cold room door 1
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Toggle setpoint
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Cold room door 2
Defrost
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Only UA 410 E AC
Subcooler controller
UK 100 E
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Manual shutdown All
1)
or
Manual shutdown Z1 /
Manual shutdown Z2
Toggle setpoint
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Defrost
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Cascade controller
KR 160 E
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Manual shutdown All
1)
or
Manual shutdown Z1 /
Manual shutdown Z2
Toggle setpoint
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Defrost
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
1)
Factory setting
2)
Freelyconfigurablealarmtext-factorysettingis“CO2Alarm”
Ifa230VACvoltageispresentatadigitalinput,theassociatedredLEDlights.Fordetailssee
chapter Status LEDs

