Menu6-2-4230VInputs
230V INPUT POS: XXXXX Entry Default
Entry1: XXXXXXXXXX Function of digital input 1 D11/D12 1) ABTAUUHR
Entry2: XXXXXXXXXX Function of digital input 2 D21/D22 2) TOGGLE SETP.
Entry3: XXXXXXXXXX Function of digital input 3 D31/D32 3) MANUAL OFF.
Entry4: XXXXXXXXXX Function of digital input 4 D41/D42 4) Extern.Alarm
XXXXXXXXXXXXXXXXXXX Freely configurable alarm text for digital input
4,thedefaulttextis“CO
2
-Alarm”
Text CO2-Alarm
Inv. D1 XXX Inverting of digital input 1 ↑,↓,(EIN/AUS) OFF
Inv. D2 XXX Inverting of digital input 2 OFF
Inv. D3 XXX Inverting of digital input 3 OFF
Inv. D4 XXX Inverting of digital input 4 OFF
Possiblesettingsforthedigitalinputs:
DEFR.TIMER Defrost timer*
MANUAL OFF. Manual shutoff both zones
MANUAL OFF. Z1 Manual shutoff only Z1
MANUAL OFF. Z2 Manual shutoff only Z2
TOGGLE SETP. Toggle setpoint
TOGGLE SETP Toggle setpoint *
MANUAL OFF Manual shutoff both zones
MANUAL OFF. Z1 Manual shutoff only Z1
MANUAL OFF. Z2 Manual shutoff only Z2
MANUAL OFF Manual shutoff both zones *
MANUAL OFF. Z1 Manual shutoff only Z1
MANUAL OFF. Z2 Manual shutoff only Z2
EXT ALARM External Alarm *
MANUAL OFF Manual shutoff both zones
MANUAL OFF. Z1 Manual shutoff only Z1
MANUAL OFF. Z2 Manual shutoff only Z2
TOGGLE SETP Toggle setpoint
*Factory setting
Menu 6-2-5 Sensor Type
Selection is made according to entry. Checkmark shows current setting
SENSORS POS: XXXXX Entry Default
L243√ Temperature range -50..50 °C
√
K277 Temperature range -50..50 °C
ATTENTION
Damage to the system and stock loss!Onlytrainedpersonnelshouldbeallowedtochangedigital
inputs, as chenges can affect other functions.

