Menu 3-3 Setpoint Toggle
TOGGLE POS: XXXXX Entry Default
Status XXX Setpoint toggle for alternative set of setpoints
(setpoint set
toggle)
Toggle Setp. XXX Setpoint toggle via:
EXT digital input D21/22
INT= internal timer
CAN= CAN bus
„—"=deactivated
↑,↓,
(EXT, INT, CAN, --)
EXT
Blind On Time X s Time for shutdown fan and cooling after toggling to
alternative
set of setpoints with external setpoint toggle (Menu
3-3)
0..250 50 sec
Toggle interv. X m The interval for the cyclical toggling between
standard and alternative setpoint data records; only
appears when the internal setpoint toggling is
activated (menu 3-3).
--, 10..60 –min
Alt ON: xxxxx hh:mm Start time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu 3-3)
↑,↓,
(Mo-Su) or
numbers
(hh:mm)
Mo-Su
21:00
AltOFF: xxxxx hh:mm End time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu 3-3)
↑,↓,
(Mo-Su) or
numbers
(hh:mm)
Mo-Su
05:00
Alt ON: xxxxx hh:mm Start time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu 3-3)
↑,↓,
(Mo-Su) or
numbers
(hh:mm)
Su
05:00
AltOFF: xxxxx hh:mm End time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu 3-3)
↑,↓,
(Mo-Su) or
numbers
(hh:mm)
Di
21:00
... A total of 7 different ON, OFF toggle times can be
entered.
Toggle time will only be obeyed when a matched
pair of ON and OFF time is set.
