• Menu 3-3 Toggle Setpoints
TOGGLE POS: XXXXX Entry Default
Status XXX Setpoint toggle for alternative set of setpoints
(setpoint set toggle)
Toggle Setp. XXX Setpoint toggle via
- EXT digital input D21/22
- INT internal timer
- CAN CAN bus
-„--“deactivated
Note: Care should be taken that the corresponding
digital input D21/D22 is set to SOLLW.UMSCH
(menu 6-2-4)
↑,↓
(EXT, INT,
CAN, --)
EXT
Toggle interv. X m The interval for the cyclical toggling between
standard and alternative setpoint data records; only
appears when the internal setpoint toggling is
activated (menu 3-3).
--, 10..60 -- min
Alt ON: xxxxx hh:mm Start time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu
3-3)
↑,↓
(Mo-Su) or numbers (hh:mm)
Mo-Su
21:00
AltOFF: xxxxx hh:mm End time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu
3-3)
Mo-Su
05:00
Alt ON: xxxxx hh:mm Start time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu
3-3)
↑,↓
(Mo-Su) or numbers (hh:mm)
Su
05:00
AltOFF: xxxxx hh:mm End time for toggle to alternative set of setpoints,
weekday from-to DD-DD, time hh:mm; shown only
when internal setpoint toggle is activated (Menu
3-3)
Su
21:00
... A total of 7 different ON, OFF toggle times can be
entered. Toggle time will only be obeyed when a
matched pair of ON and OFF time is set.
