ECKELMANN Case Controller UA 4 E Series - Page 406

Firmware V3.13
21.04.2021
406/466
•
•
•
•
Menu 6-2 Controller
CONTROLLER POS: XXXXX
1 Type and Version Move to menu 6-2-1
2 Temp. Display Move to menu 6-2-2
3 Alarm Delay Move to menu 6-2-3
4 230V Inputs Move to menu 6-2-4
5 Sensor Type Move to menu 6-2-5
6 Analog inputs Move to menu 6-2-6
7 eev ctrlr zone1 Move to menu 6-2-7; shown only when Superuser mode is activated system centre /
store computer / operator terminal (see Section Operation)
8 eev ctrlr zone2 Move to menu 6-2-8; shown only when Superuser mode is activated system centre /
store computer / operator terminal (see Section Operation)
Menu 6-2-1 Type and Version
VERSION POS: XXXXX Default
Ctrlr. Type XXXXXXX Set on DIP Switch S3 UK100E
Software Ver.: XXXX Software version of case controller
Serial No.: XXXXXX Device No. of case controller
(from EEPROM)
Menu 6-2-2 Temperature Display
DISPLAY POS: XXXXX Entry Default
Offset XX K Offset for temperature display -10..10 0 K
Alarmsymbol XX Show alarm symbol on BT 30 Temperature
Display
, ¯,
(ON/OFF)
N
Menu 6-2-3 Alarm Delay
ALARMDELAY POS: XXXXX Entry Default
Sensor Fault XX m Sensor break alarm delay 0..30 15 min
High/Low Temp. XX m High/low temperature alarm delay 0..150 90 min
No Defrost XX h No defrost alarm delay --, 2..168 --- h
Selfholding N Alarm latching with manual alarm cancelling (YES)
or automatic cancelling on send (NO)
↑,↓,
(Y/N)
N
