• Menu 1-2 Cooling Zone 1
COOLING 1 XXXXX
Cooling XXX Displays current OFF/ON status of cooling
op.deg. Z 1 XX % Displays current valve opening degree Zone 1
OD med. 24h XX % Displays mean valve opening degree Zone 1 for past day
Temp. R4.1 XXX °C Displays current refrigerant temperature Input Z21/Z22
Setpoint R4.1 XXX °C Displays refrigerant temperature setpoint for comparison
Hystersis R4.1 XXX K Displays refrigerant temperature hysteresis setpoint; shown only when on-off
control is set (Menu 2-1-1)
SH Z 1 XXX °C Displays current superheat temperature Zone 1
sup air ctrl XXX Displays current OFF/ON status of supply or refrigerant control
MOP op. XXX Displays OFF/ON setpoint of MOP mode
Status light XXX Status lighting control (ON/OFF)
Status hand XXX Status manual shutdown (ON/OFF)
