Emerson LMS1000 User Manual

Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 3-224 Chapter 3. Commands
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
SET SEQUENCE
Description: Allows configuration of the sequencer option, if furnished.
Command Level: 6
Syntax: SET SEQUENCE
SE SE
Comments: Configuration information consists of the current status of the standby and
AC sequencers. Additional information includes the Standby On/Proper Operate binary
input, the Start Delay before standby sequencing begins, Sequencer Failsafe Time, AC
Restoration Qualification Time, along with the AC Fail/Transfer binary input number and
the Input Type. The standby start delay is in seconds. After the configuration information
is displayed, the user can change the data if required.
Notes: Use of this command generates an entry into the Event Log. Sequencing affects
all rectifiers configured for energy management. The AC Restoration Qualification Timer
feature should be set to a few seconds less than the actual amount of time required for a
proper transfer. Refer also to the Configuration chapter in the separate Installation
Manual.
Related Commands: none
Example:
Command<6>: SET SEQUENCE
RECTIFIER SEQUENCING ROUTINES Current Setting (DISABLED or ACTIVE)
SEQUENCER OPTIONS:
AC Sequencer: Off
AC Fail/Transfer Input = B01
Input type: AC Fail
Standby Sequencer: Off
Standby On/Proper Operate Input = B01
Standby Start Delay: 15sec
Sequencer Failsafe time:
AC Restoration Qualification time:
AC Sequencer on (Y or N): y
AC Fail/Transfer Input = B1
Input type(Fail or Transfer): FAIL
Standby Sequencer on (Y or N): y
Standby On/Proper Operate Input = B1
Standby Start Delay: 15
Standby Start Delay:
Sequencer Failsafe time: 60
Sequencer Failsafe time:
AC Restoration Qualification time: 0
AC Restoration Qualification time:
