User Instructions Section 5847
Spec. Nos. 586505000 and 5865055000 (Model LMS1000) Issue AL, July 24, 2006
Chapter 3. Commands Page 3-339
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
<ocrdat>
This is the date when the triggering event occurred. The format for this parameter is
MOY-DOM (Month-Of-Year - Day-Of-Month). MOY ranges from 1 to 12, and DOM
ranges from 1 to 31. A NULL value for this parameter defaults to the current date unless
the <ocrtm> parameter is NULL, then this parameter does not apply.
<ocrtm>
This is the time when the triggering event occurred. The format for this parameter is
HOD-MOH-SOM (Hour-Of-Day - Minute-Of-Hour - Second-Of-Minute). HOD ranges from
0 to 23. MOH and SOM range from 0 to 59. A NULL value means this parameter and
the <ocrdat> parameter are not applicable.
<locn>, <dirn>, <aiddet>, <obsdbhvr>, <exptdbhvr>, <dgntype>, <tblistl>
These parameters do not apply or are not implemented in LMS1000. A NULL value is
inserted for them when the <tmper> parameter has a value other than NULL.
<tmper>
This is the accumulation time period for Performance Monitoring (PM) parameters. It
represents the length of time the alarm condition has been active. The format for this
parameter is VAL-UN, where valid values for VAL (value) and UN (unit) are:
VAL (value)
UN (unit)
1 DAY (day)
1 to 24 HR (hour)
1 to 1440 MIN (minute)
<conddescr>
This parameter is a text message which provides a detailed description of the alarm,
event, or condition. It is an ASCII string enclosed within a pair of escaped quotes (\"). It
may also be used to describe any action to be taken as a result of the condition. For this
application, values are derived from the CONDITION DESCRIPTION parameter of the
LMS1000 channel or limit configuration with which the alarm condition is associated. If
the channel or limit parameter has not been configured, a NULL will be inserted for this
parameter.
