Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 4-4 Chapter 4. Maintaining LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
CPU Memory
Backup Battery
(Located Behind LEDs)
(Plus Located on Top)
RS-232 Connector
Grounding Screw
(Main Cabinet Only)
Primary LMS
CPU Circuit Card
(P/N 521185)
582140000
Primary Bay
586505000
Main Cabinet
(586505500 similar)
Primary LMS
CPU Circuit Card
(P/N 514024)
Figure 4-1
Replacing the CPU Memory Backup Battery (Main Cabinet or Primary Bay Only)
