Emerson LMS1000 User Manual

Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 2-34 Chapter 2. Operating LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
CHANNEL
NUMBER
CHANNEL NAME
A9001 Vortex System Voltage
A9002 Vortex System Current
A9003 Vortex Subsystem Voltage
A9004 Vortex Subsystem Current
A9005 Vortex Total PCU Current
A9006
through
A9021
Vortex Shunt01 Current
through
Vortex Shunt16 Current
A9022
through
A9025
Vortex Temperature Probe #1
through
Vortex Temperature Probe #4
A9026
through
A9081
Vortex PCU01 Current
through
Vortex PCU56 Current
B9001 Vortex System High Voltage 1
B9002 Vortex System High Voltage 2
B9003 Vortex System Battery On Discharge
B9004 Vortex System 50% Battery On Discharge
B9005 Vortex System Overcurrent
B9006 Vortex Subsystem High Voltage
B9007 Vortex Subsystem Low Voltage
B9008 Vortex Subsystem Overcurrent
B9009 Vortex PCU Emergency Stop
B9010 Vortex System Fuse
B9011 Vortex All AC Off
B9012 Vortex MCA Fail
B9013 Vortex LVD Active
B9014 Vortex LVDs Inhibited
B9015 Vortex System Major
B9016 Vortex System Minor
B9017 Vortex Shunt Fail
B9018 Vortex LVD Fail
B9020 Vortex Battery Charge Alarm
B9021 Vortex Subsystem Fuse
B9022 Vortex Subsystem Major
B9023 Vortex Subsystem Minor
B9024 Vortex PCU High AC Line
B9025
through
B9080
Vortex PCU01 Fail
through
Vortex PCU56 Fail
Table 2-1
VPS Interface Analog and Binary Channels
