Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 2-38 Chapter 2. Operating LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
CHANNEL
NUMBER
CHANNEL NAME
A9901 LPS Plant Voltage
A9902 Total PCU Output Current
A9903 Total Load Current
A9904 Group A Load Current
A9905 Group B Load Current
A9906 reserved
A9907 Compensation Temperature
A9908
Total Auxiliary Load (only present if any LPS MCA "CAN I/O"
circuit card's analog input is configured as "auxiliary" load)
B9901 System Voltage is Very Low
B9902 System Battery is on Discharge
B9903 System High Voltage #1 Alarm
B9904 System High Voltage #2 Alarm
B9905 Total Load Current Alarm
B9906 Group A Load Current Alarm
B9907 Group B Load Current Alarm
B9908 reserved
B9909 LPS System Minor Alarm
B9910 LPS System Major Alarm
B9911 AC Power is Off to All PCUs
B9912 System Breaker or Fuse Alarm
B9913 High Temperature #1 Alarm
B9914 High Temperature #2 Alarm
B9915 Low Temperature #1 Alarm
B9916 Low Temperature #2 Alarm
B9917 Dist. Panel Alarm
B9918 Test/Equalize Mode
B9919 Emergency Stop Input
B9920 High Voltage Shutdown Input
B9921 MCA Audible Alarm Cutoff
B9922 MCA Audible Alarm
B9923 MCA Relay Test
B9924 Unidentified Node is Present
B9925 reserved
B9926 reserved
B9927 reserved
B9928 reserved
Table 2-2 (cont'd on next page)
LPS Interface Analog and Binary Channels
For LPS MCA Node (99)
