User Instructions Section 5847
Spec. Nos. 586505000 and 5865055000 (Model LMS1000) Issue AL, July 24, 2006
Chapter 2. Operating LMS1000 Page 2-39
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
CHANNEL
NUMBER
CHANNEL NAME
B9929
MCA Hardware Failure Alarm
Alarm Log Sub-ID Entries
B9929.09 Display Fail
B9929.10 Temperature Sensor No Reply
B9929.11 Any LPS Router Fail Alarm Exists
B9929.12 Any LPS Relay Board Fail Alarm Exists
B9929.13 MCA Memory Failure
B9930
MCA Hardware Install Error
Alarm Log Sub-ID Entries
B9930.09 Any LPS Device Firmware Error Exists
B9930.10 No Distribution Panel Modules Installed
B9930.11 No Routers Installed
B9930.12 No MCA Customer Alarm Relay Boards Installed
B9930.13 No PCUs Installed
B9931
through
B9946
Relay Board nn-01 Alarm
through
Relay Board nn-07 Alarm
nn = bay number
Alarm Log Sub-ID Entries
B99nn.09 Relay 1 is stuck
B99nn.10 Relay 2 is stuck
B99nn.11 Relay 3 is stuck
B99nn.12 Relay 4 is stuck
B99nn.13 Relay 5 is stuck
B99nn.14 Relay 6 is stuck
B99nn.17 Processor Failure
B99nn.18 Communications Failure
B99nn.19 Duplicate Node
nn = relay channel number, i.e. 31 for Relay 1
Table 2-2 (cont'd from previous page)
LPS Interface Analog and Binary Channels
For LPS MCA Node (99)
To Next Page
