Emerson Micro Motion 5700 Configuration And Use Manual

7 Configure device options and preferences
7.1 Configure the transmitter display
You can control the language used on the display, the process variables shown on the display, and a variety of
display behaviors.
7.1.1 Configure the language used on the display
Display Menu > Configuration > Display Settings > Language
ProLink III Device Tools > Configuration > Local Display Settings > Transmitter Display > General > Language
Field Communicator Configure > Manual Setup > Display > Display Language > Language
Language controls the language that the display uses for process data, menus, and information.
The languages available depend on your transmitter model and version.
Procedure
Set Language to the desired language.
7.1.2 Configure the process variables shown on the display
Display
Menu > Configuration > Display Settings > Display Variables
ProLink III Device Tools > Configuration > Transmitter Display > Display Variables
Field Communicator Configure > Manual Setup > Display > Display Variables
You can control the process variables shown on the display and the order in which they appear. The display
can scroll through up to 15 process variables in any order you choose. This configuration applies to both auto-
scroll and manual scrolling.
By default, one process variable is shown at a time. You can configure a custom display screen that shows two
process variables at a time.
Restriction
You cannot remove all display variables. At least one display variable must be configured.
Notes
• If you have a display variable configured to show a volume process variable, and you change Volume Flow
Type to Gas Standard Volume, the display variable is automatically changed to the equivalent GSV
variable, and vice versa.
• For all other display variables, if the process variable becomes unavailable due to changes in configuration,
the transmitter will not display that variable.
Procedure
For each display variable, select the process variable to be shown in that position in the rotation.
Configuration and Use Manual Configure device options and preferences
MMI-20025166 March 2019
Configuration and Use Manual 119

Emerson Micro Motion 5700 Specifications

General

Model	5700
Type	Transmitter
Measurement Principle	Coriolis
Enclosure	Aluminum or stainless steel
Output Signals	4-20 mA
Communication Protocols	HART
Display	Optional LCD
Operating/Ambient Temperature Range	-40 to 60 °C (-40 to 140 °F)
Materials of Construction	Stainless steel
Enclosure Rating	IP67
Hazardous Area Approvals	ATEX, IECEx
Diagnostics	Comprehensive diagnostics available
