Connect H90 Output 1 and 2 to aux return 1 of your mixing console or to a pair of Inputs on your
audio interface.
Connect another stereo pair of Outputs from your mixing console or audio interface to H90 Input 3
and 4.
Connect H90 Output 3 and 4 to aux return 2 of your mixing console or to a pair of Inputs on your
audio interface.
Press the Routing Button and turn Quick Knob 1 to adjust the routing position to Pre/Post. When
you send audio to aux channel 1 of your mixer, it will be processed by Preset A on Path 1. Audio that
is sent to aux channel 2 of your mixer will be processed by Preset B on Path 2.
Consult the documentation for your DAW or audio interface for additional instructions to send
audio to and from them.
Check out Dual Routing (Section 6.2.2) for more info.
Tip
If you’d like the H90’s tempo to sync to an external MIDI device via DIN or USB, navigate to the
Tempo Menu (Section 8) and set the Tempo Source appropriately.
•
•
•
•
•
•
3. SETUP
