Kill Dry
This is the global kill dry setting that all Programs and presets will subscribe to. If a Program or Preset’s kill
dry setting is set to Global, it will reflect this setting of on or off.
Pedal Control
Global Pedal Control allows you to define external controllers such as aux switches and expression pedals
that will always affect the H90, regardless of what Program is loaded. For example, if you’d like Aux Switch 1
to always perform the Load action, you can configure this using the Global Pedal Control.
Parameter: Turn Quick Knob 1 to select a parameter.
Control Source: Turn Quick Knob 2 to select control source for the currently selected parameter.
Note
Check out the Global Mapping Chart (Section C) for a full list of available mappings.
7.2. I/O
In/Out Levels
Individually adjust inputs and outputs between instrument level and line level. An LED grid on the back of the
H90 also indicates which jacks are set for line level signals.
•
•
7. SYSTEM MENU
