6.2.2. Dual Routing
Dual Routing allows you to route two processing paths within your H90. This can be used to process two
instruments separately through two different Presets, or to connect to an amplifier in a Pre/Post
configuration using one Preset in your preamp section and one Preset in your amp’s effects return.
 Note
Programs using Dual Routing will display in the top right corner.
Fig. 6.15 Programs using Dual Routing
Turn Quick Knob 1 to change the routing position for Presets A and B on Paths 1 and 2.
Quick Knob 2 and 3 are non-functional when Routing Mode is in Dual Routing configuration.
Dual Routing enables two separate signal paths:
Path 1: Inputs 1/2 to Outputs 1/2
Path 2: Inputs 3/4 to Outputs 3/4
Dual Routing Positions
Routing Path 1 Path 2
Path 1 Series Series Thru
Path 1 Parallel Parallel Thru
Pre/Post Preset A Preset B
Path 2 Parallel Thru Parallel
Path 2 Series Thru Series
•
•
•
•
•
