104
MB1 User Manual
© 2016 Expert Electronics
MAIN SCREEN DESCRIPTION
To transfer the IQ signal in the CW Skimmer you need to adjust the settings of the audio
device in the RX IQ output category, it consists of:
· Enable checkbox - Enable the IQ signal transfer from the EpertSDR2 to the CW Skimmer.
· Driver – audio device driver type.
· Output – audio device physical output.
· Channels – amount of the used channels of the audio device.
· Sample rate – sampling frequency.
· Buffer size – buffer size.
· Latency – signal delay time.
Note:
(
If CW Skimmer is installed on the transceiver's PC, then for the signal output you need to use
Virtual Audio Cable.
· Sync frequency - ExpertSDR2 set the CW Skimmer frequency.
· Tune frequency from CW Skimmer - CW Skimmer set the ExpertSDR2 frequency.
