MB1 User Manual
© 2016 Expert Electronics
TRANSCEIVER OPERATIONS
2. When the playback ends you'll hear the receiver's air again.
Note:
(
Attention, recordings of the air signals should be used for personal use only. MB1 operator
bears full responsibility for using the recorded signal.
(
In the voice Mic you may record your own CQ (come quick) signal and transmit it on the air by
pressing the Play button .
7.38 Transverter mode operation
Will be available in the future software releases.
7.39 External PA control
The transceiver allows you to control the TX mode of the external power amplifiers (PA).
1. Set the Enable checkbox.
2. Connect the PTT control line of the external PA to one of the PTT sockets (more details in
Linear Amplifier ).
3. Open the software Options-> Device menu-> PA tab.
4. Set the checkboxes for the required bands opposite the used key.
Note:
(
Choose the electronic keys, which will be activated on the certain bands. The same key could
be used on several bands.
(
Example: If you use wide-band PA 160М-10М bands and control it via the #1 key, then set
the checkboxes for the #1 key, opposite the corresponding bands.
21
