MB1 User Manual
© 2016 Expert Electronics
TRANSCEIVER OPERATIONS
BALANCE B - VFO B volume balance control between left and right channels.
· RX1 - Enable RX1 volume and balance controls.
Press the RX1 to enable volume and balance control for VFO A, VFO B of the RX1.
· RX2 - Enable RX2 volume and balance controls.
Press the RX2 to enable volume and balance control for VFO A, VFO B of the RX2.
· VOLUME A - VFO A volume control.
Set the required volume for the VFO A receiver.
· BALANCE A - VFO A volume balance control between left and right channels.
Set the required volume balance control between left and right VFO A channels.
· VOLUME B - VFO B volume control.
Set the required volume for the VFO B receiver.
· BALANCE B - VFO B volume balance control between left and right channels.
Set the required volume balance control between left and right VFO B channels.
· SDR SOUND - Audio output from the transceiver.
Press the SDR SOUND to listen to the transceiver's received signals.
· PC SOUND - Audio output from the PC.
Press the PC SOUND to listen to the audio from PC, e.g. audio, video files, web browsing,
SKYPE etc.
· SPEAKER - Audio output to the speaker.
Press the SPEAKER to listen to the audio via the speaker.
7.8 Selecting the Operating Band
Select the operating band by pressing the band buttons on the front panel of the transceiver.
You can use the following band buttons: 160, 80, 40, 30, 20, 17, 15, 12, 10, 6, 2 Meters.
Press the button of the required band to switch to it.
Note:
(
Band buttons have 3 position memory. Successive presses of the band button cycles through
memory position (more details in Using the Band Memory ).
