SPLIT OPERATION
10
SUB RECEIVER USING
If you want to listen the VFO A and VFO B frequencies simultaneously, use Sub-receiver.
1. Activate Sub-receiver by pressing the SUB button, on the front panel of the transceiver.
Flashing blue indicator in the main software window means the Sub-receiver is
enabled.
2. Set the required VFO B frequency (more details in VFO A and VFO B control ).
3. Listen to the VFO A and VFO B frequencies simultaneously. If you need to adjust the
Volume and Balance of each VFO A and VFO B (more details in Audio signals routing ).
Note:
( VFO A receiver's red tuning line means that in Sub-RX mode you'll transmit on the VFO A
frequency.
( To turn the Sub-receiver to transmit, press TX B or SPLIT .
