TRANSCEIVER OPERATIONS
2. Press again the Rec button
on the front panel of the transceiver to stop the recording.
Red LED indicator on the left of the Rec button will stop blinking.
Note:
(
Recording of the received signal is available in all mode types.
Record of the microphone signal:
1. Press the РТТ button on the microphone or the ТХ button on the front panel of the
transceiver.
Transceiver will turn to TX mode.
2. Press the Rec button
on the front panel of the transceiver to start the recording and
begin to speak in the microphone.
Red LED indicator on the left of the Rec button will start blinking.
3. Press again the Rec button
on the front panel of the transceiver to stop the recording.
Red LED indicator on the left of the Rec button will stop blinking.
Play the recorded signal without transmitting it on air:
1. Press and hold (~1 sec) the Play button
on the front panel of the transceiver to play
the recorded voice signal.
With that in phones (internal speaker) you'll hear the recorded voice signal, meantime receiver
will be silent.
2. When the playback ends you'll hear the receiver's air again.
Play the recorded signal with transmitting it on air:
1. Short press the Play button
on the front panel of the transceiver to play the recorded
voice signal and transmit it on the air.
With that the transceiver will turn to TX mode, in phones (internal speaker) you'll hear the
recorded voice signal and it will be transmitted on the air.
