MB1 User Manual
© 2016 Expert Electronics
MAIN SCREEN DESCRIPTION
Sound out from PC - Sound output from the internal PC goes in the mixer.
Set the Sound out from PC checkbox, if you want the sound output from the internal PC pass
in the mixer to listen to the received signals via the internal speaker and/or headphones via the
PHONES jack.
Speaker - Internal speaker checkbox.
Set the Speaker checkbox to play sounds via the internal speaker.
Note:
( Checkboxes are doubled by buttons in the software main window in the Mixer local panel
(more details in MIXER ). In other words, you don't have to open the MB1 utility to control
sound output, you can do it in the EXpertSDR2 software.
Fan speed category.
Mode - Fan mode indicator.
Fan indicator shows current fan mode.
PA voltage - PA voltage indicator.
PA current - PA current consumption indicator.
SDR voltage - SDR-module voltage indicator.
SDR current - SDR-module current consumption indicator.
PC current - PC current consumption indicator.
ACC current - Accessories current consumption indicator.
SYS voltage - Power supply output voltage indicator.
Temperature - Transceiver temperature indicator.
57
