TRANSCEIVER OPERATIONS
· Fast tuning by the mouse click.
Rollover mouse cursor on the required place on the spectrum scope or waterfall and click the
left mouse button - receiver's filter will move to this location.
Note:
( If the Sub-receiver or the SPLIT mode is enabled, then for the Fast tuning by the
mouse click between VFO A and VFO B press the mouse wheel on the spectrum scope
or waterfall. While tuning, color of the mouse cursor will match the controlled receiver - color of
the mouse cursor also match the receiver's tuning line.
( Fast tuning by the mouse click tuning mode is convenient in combination with the
Rotating the mouse wheel mode. Mouse click on the station's signal and perform fine
tuning with the wheel if you slightly missed.
· Moving the receiver's filter over the spectrum scope.
Place the mouse cursor approximately in the middle of the receiver's filter, press the left
mouse button and while holding it drag the receiver's filter - it will follow the mouse cursor over
the spectrum scope. Release the left mouse button when the signal match the filter position -
receiver's filter will hold its position after you release the button.
· Moving the Spectrum Scope ( filter holds its position ).
Press the right mouse button on any place over the spectrum scope or waterfall and while
holding it drag the spectrum scope until the required frequency match the filter position.
Tuning is carried out with the current STEP value.
· Moving the receiver's filter with the Spectrum Scope (tuning frequency won't change).
Place the mouse cursor approximately in the middle of the receiver's filter, press the right
mouse button and while holding it drag the receiver's filter - it will follow the mouse cursor over
the panorama along with the spectrum scope. Release the button to stop tuning.
Note:
( Basically it is not tuning, but it allows you to look at the air beyond the panorama window,
without detuning the receiver.
· Mouse click on the digit position of the frequency indicator.
Rollover mouse cursor on the required digit position of the frequency indicator and click left
mouse button - digit position value will one up.
Rollover mouse cursor on the required digit position of the frequency indicator and click right
mouse button - digit position value will one down.
