ATU OPERATION
BYPASS - The tuner's Bypass mode button.
Press the BYPASS to enable tuner's bypass mode to exclude it's influence on the transceiver.
RX - Enable the Tuner for the RX mode.
Press the RX button to enable matching in the RX mode.
Note:
( The Tuner cannot do matching in the RX mode . The Tuner can only use saved earlier states
from the TX mode.
TX - Enable the Tuner for the TX mode.
Press the TX button to enable matching in the TX mode.
RX AFTER TUNED - "RX after tuned" enable button.
Press the RX AFTER TUNED button and the transceiver will turn to the RX mode after the
tuner is tuned.
