MB1 User Manual

MAIN SCREEN DESCRIPTION

· Averaging type - Spectrum scope averaging type menu.

Choose the averaging type from the list: Linear, root-mean-square (Rms), Exponential, which

suits you best.

· Averaging num - Amount of samples for averaging.

Set the required amount of samples for averaging. The bigger the amount of samples, the

slower the specter will change on the graph.

· Update period - Spectrum scope update period.

Set the required specter's graph update period. The bigger the number, the more FPS on the

spectrum scope, along with the higher processor load.

· Render mode - Specter render mode: lines, gradient.

Set the required specter render mode.

· Line color - Spectrum scope line color.

Choose the required line color from the palette.

· Fill color - Fill color of the spectrum scope lower area.

Choose the required fill color from the palette.

· Fill transparency - Transparency slider for the spectrum scope lower area filling.

Set the required filling transparency level.

· Show bands - Show amateur bands borders.

Set the Show bands checkbox to show amateur bands borders at the top of the spectrum

scope (blue line).

· Save limits for each band - Save spectrum scope amplitude limits for each band.

Set the Save limits for each band checkbox to enable the software to save set spectrum

scope limits for each band.

· Save zoom for each band - Save spectrum scope zoom settings for each band.

Set the Save zoom for each band checkbox to enable the software to save spectrum

scope zoom settings for each band.

· Zoom center follows VFOA - Zoom center marker locked on the VFOA position on the

spectrum scope.

Set the Zoom center follows VFOA checkbox to enable zoom center marker lock on the

VFOA position.

· Animation - Spectrum scope animation while transition between bands.

Set the Animation checkbox to enable animation.

· Show cursor info - Show frequency and dB level of the cursor position.

Set the Show cursor info checkbox to enable info display near the cursor on the spectrum

scope.
