MAIN SCREEN DESCRIPTION
· Enable CAT – Checkbox to enable control of the transceiver via the CAT-system.
· Port name – COM-port number.
· Parity – Parity.
· Data – Amount of data in bits.
· Stop bit – Amount of stop bits.
· Baud rate – Port speed.
· PTT line – COM-port line to activate the TX mode.
· Key line - COM-port line for the CW mode.
· DTR/RTS – COM-port line for the PTT mode.
· Enable SubRX control (FR command) - Checkbox to enable control of the sub-receiver
via the CAT-system.
Set the Enable SubRX control (FR command) checkbox to enable the control of the sub-
receiver via the CAT-system.
· Antenna switch control – Checkbox to enable control of the antenna switch via the CAT-
system.
Set the Antenna switch control checkbox to enable the control of the antenna switch via
the CAT-system. Useful for the Ham Radio Deluxe software.
· Enable PTT – Checkbox to enable control of the TX mode via the COM-port.
Set the Enable PTT checkbox to enable the control of the TX mode via the COM-port.
· Port name – COM-port number.
· DTR/RTS – COM-port line for receiving the PTT commands.
Set one of the DTR/RTS line checkbox to select them as control.
· Enable Switch – Checkbox to enable control of rerouting the PTT signal from footswitch to
additional COM-port.
Set the Enable PTT checkbox to enable rerouting the PTT signal from footswitch to
additional COM-port.
· Port name – COM-port number.
· DTR/RTS – COM-port line for receiving the PTT commands.
Set one of the DTR/RTS line checkbox to select them as control.
