MAIN SCREEN DESCRIPTION
· Enable SubRX control (FR command) - Checkbox to enable control of the sub-receiver
via the CAT-system.
Set the Enable SubRX control (FR command) checkbox to enable the control of the sub-
receiver via the CAT-system.
· Enable PTT – Checkbox to enable control of the TX mode via the COM-port.
Set the Enable PTT checkbox to enable the control of the TX mode via the COM-port.
· Port name – COM-port number.
· DTR/RTS – COM-port line for receiving the PTT commands.
Set one of the DTR/RTS line checkbox to select them as control.
· Enable Switch – Checkbox to enable control of rerouting the PTT signal from footswitch to
additional COM-port.
Set the Enable PTT checkbox to enable rerouting the PTT signal from footswitch to
additional COM-port.
· Port name – COM-port number.
· DTR/RTS – COM-port line for receiving the PTT commands.
Set one of the DTR/RTS line checkbox to select them as control.
