Extra 300LX - 32-40-01 Master Cylinder; 32-40-02 Wheel Fairing

CHAPTER 32
PAGE 10
PAGE DATE: 1. March 2011
MAINTENANCE MANUAL EXTRA 330LX
32-40-01 Master Cylinder
Removal/Installation
1 Drain the brake system.
2 Disconnect the brake lines.
3 Remove the attachment bolts.
4 Remove the master cylinder.
5 Install in reverse sequence of removal.
32-40-02 Wheel Fairing
The wheel fairings are made from glass fiber. The layer
sequence is shown on figure 5.
Removal/Installation
The wheel fairings are screwed on.
