Flex I/O Applications
This section provides basic instructions on how to use each supplemental plug-in
application (app) available for the SMP351. Topics include:
• About the FlexOS App - Digital I/O Configurator
• Access the Application
When an app is downloaded and installed (see Advanced Features on page125), a user
must have administrator privileges to access the Advanced Features page and to use these
applications. The apps are available on the SMP351product page at www.extron.com.
About the FlexOS App - Digital I/O Configurator
This application allows you to first configure and label the digital input/output (I/O) ports and
then create up to 16 different monitors that check for conditions and apply actions when the
conditions are met.
Below are basic instructions on how to use the Digital I/O Configuration plug-in application
(app) available for the SMP351 once it has been downloaded and installed. A user must
have administrator privileges to access the Advanced Features page of the SMP351
embedded Web pages and to use this application.
Access the Application
To access the Digital I/O Configuration app:
1. Open the SMP351 embedded Web pages:
a. Open a Web browser.
b. Enter the SMP351 IP address into the address field and navigate to the unit. If no
passwords are set for the unit, the embedded Web pages open automatically to the
Recording Controls page. If one or more passwords are set for the SMP351 ,
a dialog box opens and prompts the user to enter a user name and password.
c. If necessary, enter an administrator level user name and password.
d. Click Log In or OK. The SMP351 embedded Web page opens to the
RecordingControls page.
2. Click the Configuration tab at the top of the SMP351 embedded Web pages.
3. Click the Advanced Features tab on the second tier of tabs. You may need to scroll
the page to the right or scroll the second tier of tabs to see Advanced Features at
the far right.
SMP351 • Flex I/O Applications 149
