Advanced Features
In the Advanced Features page within Configuration, an administrator can do the
following things:
• Set the SMP351 to run a Web browser client application for direct control on site when
a network-connected computer is not available.
• Upload a plugin application to add functions and configuration options, then use the
plugin to configure features of the SMP351.
These settings are available only via this page. They cannot be set via the front panel.
To open this page, click Configuration > Advanced Features. You may need to
scroll the page to the right or scroll the second tier of tabs to see Advanced Features at
the far right.
The Advanced Features page opens, showing the Browser Client and Apps panes.
Figure 77. Advanced Features Page
Connect a keyboard and mouse to control the SMP351
You can configure the SMP351 to run a Web browser client application for direct control if a
stand-alone computer is not available on site. If enabled, the internal Web browser provides
access to a subset of the Network (IP) Settings configuration pane.
To set up the SMP351 for local control using its internal browser client:
1. On a computer connected to the same network as the SMP351, open a browser, enter
the IP address of the unit into the address field, and connect to the embedded Web
pages.
2. Click the Configuration tab at the top of the SMP351 embedded Web pages and
then click the Advanced Features tab on the second tier of tabs.
3. Select (check) the Enable the browser client? checkbox in the Browser
Client panel.
NOTE: The following steps do not require a computer and do not require the SMP351
to be connected to a network.
4. Connect a monitor and a keyboard and mouse directly to the SMP351 (see Control
System and External Device Connections on page15).
• Connect the keyboard to either the front or the rear USB port, or to the rear panel
Mouse/Keyboard USB connectors.
• Connect the mouse to the other (rear or front) USB port or to the rear panel
Mouse/Keyboard USB connectors.
• Connect a display to the local HDMI output port on the rear panel.
SMP351 • Web-Based User Interface 125
