Command and Response Tables
Command
Function
SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Information requests
NOTE: An asterisk (*) after the version number indicates the currently running version. Question marks (?.??) indicate that only factory
firmware is loaded. A caret (^) indicates the firmware version that should be running, but a Mode1 reset (see SMP351 Rear
Panel Reset on page16) was executed and the default factory firmware is running. An exclamation point (!) indicates
corrupted firmware.
Firmware version
Q or 1Q
X1!]
Firmware version to 2 decimal
places (1.00)
Firmware and build
version
*Q/q
X1!]
Firmware version to 2 decimal
places plus build number to 4
decimal places (1.12.1234)
Verbose version
info
0Q
Sum of 2Q-3Q-4Q
]
Show bootstrap, factory-
installed, and updated firmware
version.
Bootstrap Version
2Q
X1! ]
The bootstrap firmware is
not user replaceable but you
may need this information for
troubleshooting.
Factory Firmware
Version
3Q
X1!
plus Web ver.-desc-UL date/
time
]
Factory installed firmware is not
user replaceable. This firmware is
the version the SMP351 reverts
to after a mode 1 reset.
Example:
3Q
1.00.0000-b2325(1.81LX-
SMP351 -Sat, 01 Nov 2014
20:10 UTC)
Updated firmware
version
4Q
X1!
plus Web ver.-desc-UL
date/time
]
Use this command to find
out which version of firmware
has been uploaded into the
SMP351.
Example:
4Q
1.00.0004-b2635*(1.81LX-
SMP351 -Sun, 02 Nov 2014
00:12 UTC)
Query part number
N
60-1324-01
]
60-1324-01: SMP 351 or
60-1324-02: SMP 351 3G-SDI
Query model name
1I
SMP •351
]
SMP 351 or SMP 351 3G-SDI
Query model
description
2I
Streaming•Media•Processor
]
Query system
memory usage
3I
#Bytes used out of #KBytes
]
View number of
connected users
10I NN
# of users
View system
processor usage
11I NN
Returns a percentage of total.
View system
processor idle
12I NN
Returns a percentage of total.
View eth0 link
status
13I
Current link state (up/down)*
speed in MB (10/100/1000)*
mode (full/half)
View file transfer
config
38I
in json format
View active alarms
39I [name:alarm_name],[level:alarm_level]...]
NOTES: X1! = Version number Firmware version number to second decimal place (x.xx)
Version and Build number adds four digits (x.xx.xxxx)
to the Version number
164SMP351 • Remote Communication and Control
