Input Configuration Menu
This menu allows the user to configure each of the five inputs.
NOTE: The Input Configuration submenus are input specific. Depending on the input
type, not all submenus (shown in gray on subsequent pages) are available.
From the Input Config menu, press NEXT to enter
the submenu (see image at right).
Input Select
The first submenu is the input selection (see image
at right). Rotate either ADJUST knob to select the
desired input number from the active front panel input
selections for further configuration. This selection
determines the subsequent submenus that are visible.
Input format
The next submenu selects the input signal format (see image at
right).
INPUT #1 INPUT #2 INPUT 3 INPUT 4 **INPUT 5
*HDMI *HDMI *YUVp/HDTV *HDMI *Auto-SDI
YUVi 3G-SDI
Composite HD-SDI
SDI
*Default
**Input 5 requires an optional 3G/HD/SDI input card.
NOTE: When there is no active input, the input parameters show "N/A". For digital
inputs, H/V start, H/V active, total pixel and phase submenus do not apply.
Film detection (interlaced input formats only)
Film detection is automatically enabled when an interlaced input format is selected (see
Input format above). Film detection supports 2:2 and 3:2 detection. The processing
maximizes image detail and sharpness for interlaced sources that originated from film. Film
detection is valid for any interlaced input type. The SMP351 de-interlaces NTSC, PAL, and
1080i inputs.
If PIP mode and film detection are on for both inputs, the priority is given to the interlace
input. If both inputs are interlaced, priority is first to the larger window size, or to the main
window.
Film detection mode cannot be disabled and has no user adjustments.
Menu
Next
INPUT
CONFIG
Rotate either to
select the input format.
Rotate = to select the horizontal
start pixel.
Rotate ] to adjust the vertical
start pixel.
Rotate = to adjust Horizontal Active pixel
width.
Rotate ] to adjust Vertical Active pixel height.
Rotate = to set an
EDID value for the
active input.
Rotate either to
select input.
Rotate either to
select an aspect ratio for the
selected input.
Rotate either to
select an audio input source
for the selected input.
Rotate either to set the
audio input level from -18
to +24 dB.
NOTE: The Input Configuration submenus are input
specific. Depending on the input type, not all
submenus (shown in gray on subsequent pages)
are available.
Rotate = to adjust TTL pixel width.
Rotate ] to adjust phase.
INPUT SELECT
<1>
INPUT #[3]
<AUTO DETECT>
(3) TTLPIX PHASE
<XXX> <16>
EDID INPUT #[1]
<720p_60_2ch>
(3) H START V
<128> <128>
(3) H ACTIVE V
<1024> <0768>
ASPECT RATIO IN[1]
<FILL>
IN[1] AUDIO SELECT
<LPCM 2CH>
IN[1] AUDIO LEVEL
<0 dB>
Menu
Next
INPUT
CONFIG
Rotate either to
select the input format.
Rotate = to select the horizontal
start pixel.
Rotate ] to adjust the vertical
start pixel.
Rotate = to adjust Horizontal Active pixel
width.
Rotate ] to adjust Vertical Active pixel height.
Rotate = to set an
EDID value for the
active input.
Rotate either to
select input.
Rotate either to
select an aspect ratio for the
selected input.
Rotate either to
select an audio input source
for the selected input.
Rotate either to set the
audio input level from -18
to +24 dB.
NOTE: The Input Configuration submenus are input
specific. Depending on the input type, not all
submenus (shown in gray on subsequent pages)
are available.
Rotate = to adjust TTL pixel width.
Rotate ] to adjust phase.
INPUT SELECT
<1>
INPUT #[3]
<AUTO DETECT>
(3) TTLPIX PHASE
<XXX> <16>
EDID INPUT #[1]
<720p_60_2ch>
(3) H START V
<128> <128>
(3) H ACTIVE V
<1024> <0768>
ASPECT RATIO IN[1]
<FILL>
IN[1] AUDIO SELECT
<LPCM 2CH>
IN[1] AUDIO LEVEL
<0 dB>
SMP351 • Front Panel Operation 34
