Frame Rate (video)
Archive and confidence encodes have independent frame rate settings. This menu provides
a frame rate selection (frames per second) from the following list:
• 30 (default) • 12.5
• 25 • 12
• 24 • 10
• 15 • 5
Frame rates are selected separately for the archive and confidence encoder configurations.
Bit Rate (Video)
Archive and confidence encodes have independent video bit rate settings. Video (VID) bit
rate sets a target video bit rate from 200 kbps to 10000 kbps (default 5000 kbps).
Rotate the left (
[
) ADJUST knob to select the video bit rate.
Bit Rate (Audio)
Archive and confidence encodes have independent audio bit rate settings. Audio (AUD) bit
rate allows the user to select an audio bit rate in kbps from the following selections:
• 80 • 96 • 128
• 192 (default) • 256 • 320
Rotate the right (
{
) ADJUST knob to select an audio bit rate.
SMP351 • Front Panel Operation 33
