Overview of the Web-Based User Interface
The SMP351 embedded Web pages provide the software user interface for operating and
configuring the SMP351 via a control PC on the same network.
NOTE: Google Chrome was used to take the SMP351 user interface screen shots in
this user guide. Pages and panels viewed in other browsers may not appear exactly
the same.
Input 5
Input 4
Input 1
Input 2
Input 3
Figure 19. SMP351 Embedded Web Pages
