• Universal OSD – This pattern consists of a small, translucent, gray rectangle with
white text overlaid atop the source video content. It appears in the upper left of
the screen. The text includes brief text of your choice followed by three selectable
elements separated by commas (see Setting up the universal OSD test pattern on
page80).
Rotate either ADJUST knob to scroll through the the patterns. Stop on the desired pattern
and press NEXT. The selected test pattern is immediately output to the display. The test
pattern displays until another pattern is selected, Off is selected from the TestPattern
drop-down list, or unit power is recycled.
Record Drive Limiter
This submenu allows the record drive locations to be limited or to
be fully automatic.
The following limitations can be selected:
• NOT RESTRICTED (default) – Allows recording to internal
memory and any connected drives.
• AUTO – See Record To (archive only) on page30.
• INTERNAL ONLY – Records only to the internal storage.
• FRONT USB ONLY – Records to a device connected to the front USB port only.
• REAR USB ONLY – Records to a device connected to the rear USB port only.
Based on the top level selection, the REC LOCATION submenu under Record/Stream
Config offers different record drive options.
NOTE: Recordings are saved to the designated destination only (for example: the
FRONT USB ONLY selection limits the recording location to the front USB port even if
the drive is disconnected or fails.
Reset
The Reset submenu provides a factory reset or firmware reboot. The selections are:
To Factory – Equivalent to a ZXXX command (see Command and Response Tables on
page164). The unit is reset to factory defaults with the current firmware.
Reboot Unit – Identical to a power cycle.
A reset or reboot confirmation message appears before the reset or reboot. Upon
confirmation, the front panel LCD displays "Resetting/Rebooting Unit".
MenuMenu
1H[W
1H[W
1H[W
1H[W
1H[W
1H[W
1H[W
ADVANCED
CONFIG
Rotate ] to toggle Auto
Memory On or Off.
Rotate either to select reboot or
to reset all advanced configurations.
Rotate either to select a
test pattern.
Rotate = to select input.
Rotate ] to toggle on or off.
Rotate either to select a
resolution.
Rotate either to select
the drive restriction.
IN<1> AUTO IMAGE
<OFF>
TEST PATTERN
<N/A>
RESET
<NONE>
AUTO MEMORY
<ON>
PREVIEW HDMI OUT
<1280X720@60Hz>
RECORD DRIVE LIMITER
<NOT RESTRICTED>
SMP351 • Front Panel Operation 41
