FaroArm® Quantum
August 2017
101
Chapter 4: Probes
3. Digitize the white area of the FARO Compensation Plate with the FARO
Laser Line Probe in a sweeping motion. You should collect at least 200 scan
lines in the FARO Laser Line Probe compensation. If not, repeat the
compensation moving the FARO Laser Line Probe slower in each step.
• Rotate the FARO Laser Line Probe 90°.
• Aim the laser line at the middle of the white surface.
• Move the FARO Laser Line Probe until the laser is in the
Center Range .
• Press and hold the green Front button and move the FARO Laser Line
Probe while pointing to the center of the white surface. Rotate the
FARO Laser Line Probe as much as possible - at least 90 degrees.
• Press the red Back button.
08m80e00_FaroArm_Quantum.book Page 101 Tuesday, August 22, 2017 11:03 AM
