Chapter 8 System Operation
PAGE 8- 11
Fastening Result Display Mode example
「
「「
「D-No.
..
.」
」」
」 「
「「
「DATA」
」」
」
Peak Torque
Final Angle
Rate 1
Tool Cycle Count (x1)
■
■■
■ Rate 1 (Low) ■
■■
■ 1st NG Item (300=Rate 1) ■
■■
■ Rate 1/2/3 Judgment (Rate 1 low)
■
■■
■ No. of Fastening Steps ■
■■
■ Fastening Method (Torque) ■
■■
■ Reverse Flag
･
･･
･ The displayed contents of the following D-
Nos. are not stored in the fastening
result retention (in the controller)
D-No. 12 “Fastening Method,” D-No. 13 “Number of Fastening Steps,”
D-No. 14 “Self-Checking Flag,” D-No. 15 “Reverse Flag,” and
D-No. 16 “Servo Lock Flag.”
～
[ ▲ ] or [ ▼ ] push-button
(Skip 5 numbers while holding down)
000
001
002
035
