When an error occurs (ABNORMAL signal “ON”)
If an Abnormal occurs, the controller will display the abnormal code and subcode. (“A03_02” shown below)
The code can be used to lookup further diagnostic / troubleshooting information in the manual
(See Chapter 10)
■
■■
■
When the BYPASS signal is turned “ON”
■
■■
■
When the RESET signal is turned “ON”
■
■■
■
When the STOP signal is turned “OFF”
■
■■
■
When the indicator CAL switch is turned “ON”
“Bypass”
“Stop”
“Reset”
“CAL”
