Chapter 8 System Operation
PAGE 8- 33
[System Parameters – continued]
D-No. 010 Controller maximum current Cannot be changed.
This indicates the maximum current value of the controller
D-No. 011 IP Address (upper 6 digits) D-No. 012 IP Address (lower 6 digits)
Setting range: 0 to 255
The IP address for the controller Ethernet port is set here. In a MULTI system, the Ethernet port for the
MASTER spindle is only used. (Slave spindles will still display IP addresses, but are not used)
* D-Nos. 011 to 016 become available upon rebooting the control power after being changed.
D-No. 013 Subnet Mask (upper 6 digits) D-No. 014 Subnet Mask (lower 6 digits)
Setting range: 0 to 255
The subnet mask is set here.
* D-Nos. 011 to 016 become available upon rebooting the control power after being changed.
D-No. 015 Default Gateway (upper 6 digits) Setting range: 0 to 255
D-No. 016 Default Gateway (lower 6 digits) Setting range: 0 to 255
The default gateway is set here.
* D-Nos. 011 to 016 become available upon rebooting the control power after being changed.
D-No. 017 MAC Address (upper 6 digits) Cannot be changed.
D-No. 018 MAC Address (lower 6 digits) Cannot be changed.
The MAC ID address of the Ethernet port is indicated.
D-No. 019 RTC: Year/Month/Day Setting range: 13 to 99 (year), 1 to 12 (month), 1 to 31 (day)
D-No. 020 RTC: Time Setting range: 0 to 23 (hours), 0 to 59 (minutes), 0 to 59 (seconds)
The date and time of the real time clock (RTC) are indicated. The range for the year is 2013 to 2099.
* This is not indicated at a SLAVE spindle in a MULTI system.
D-No. 021 Erase Fastening Result History/Format CF Card
Erasing of the fastening results history can be executed. Please refer to “Copying of Parameters and
Erasing of the Fastening Result History” in Section 8-6 regarding the method for erasing the fastening
results history.
Also, if the Expansion Unit 2 (Model: MFC-CF) is installed, formatting of the CF card can be executed.
Please refer to “Formatting the Memory Card” regarding the method for formatting the CF card.
D-No. 022 Parameter Copy
Copying of parameters is performed. Please refer to “Copying of Parameters and Erasing of the
Fastening Result History” on Section 8-6 regarding the method for copying parameters.
D-No. 023 For in-house adjustment
Not used.
D-No. 024 FPGA Version of controller
This indicates the FPGA (Field Programmable Gate Array) version number of controller.
D-No. 025 FPGA version of MFC-CF module
This indicates the FPGA (Field Programmable Gate Array) version number of MFC-CF module.
