Chapter 8 System Operation
PAGE 8- 34
[System Parameters – continued]
D-No. 100 Connected Tool No.
The nutrunner Tool No. corresponding to the connected tool model is indicated. Please refer to “Tool
Models” in Section 2-2-3
D-No. 101 Connected Tool Information
The Tool model and motor model are indicated. (ex. “101rS1” or “132rS3”)
D-No. 102 Tool CAL Torque Decimal Point
The decimal point of the D-No. 103 “Tool CAL Torque” is indicated.
D-No. 103 Tool CAL Torque [N
m]
The CAL torque of the tool is indicated.
D-No. 104 Tool CAL Voltage [V]
The CAL voltage of the tool is indicated.
D-No. 105 Tool ZERO Voltage [V]
The ZERO voltage of the tool is indicated.
D-No. 106 Tool Internal Gear Ratio (×100)
The value obtained by multiplying the gear ratio of the tool by 100 is indicated.
D-No. 107 Tool Serial No. (upper 3 digits) D-No. 108 Tool Serial No. (lower 4 digits)
The serial No. of the tool is indicated.
D-No. 109 Tool Rotation Direction
The rotation direction of the tool is indicated. (CW: 0, CCW: 1)
D-No. 110 Tool Order No. (upper 2 digits) D-No. 111 Tool Order No. (lower 5 digits)
The internal sales order No. of the tool is indicated.
D-No. 112 Tool Cycle Count (×1 million)
D-No. 113 Tool Cycle Count (×1)
Indicates the total cycle count of the connected tool.
* When the count is less than 1 million, [------] is indicated for D-No. 112.
