Chapter 3 System Description
PAGE 3-17
● List of System Wiring Diagram Cables (Color Code matches diagram on previous pages)
No. Item Standard length Part # Remarks
1
Standard Tool Cable
(for MFC-S024 / 60)
5, 7.5, 10, 12.5, 15,
20, 25, 30 meter
FEB-1630-Mx
Replace “x” with length
2
Extension Tool Cable
(for MFC-S024 / 60)
3, 5, 7.5, 10, 12.5,
15 meter
FEB-1630E-Mx
Replace “x” with length
--
AFC1500 Tool Cable
Adapter
--- FEB-1648
For NFT RM4 tools
only
3
Drive Power Cable
(for MFC-S024 / 60)
3[m]
FEB-1260
(Was FEB-1631)
Included with the MFC
controller
4 Control Power Connector
--- MC1.5/3-STF-3.81*
Included with the MFC
controller
5 STOP Signal Connector --- MC1.5/2-STF-3.81*
Included with MFC
controllers ordered with
Fieldbus Units only
6
PC Communication
Cable (Crossover)
2[m] FEB-1331
For direct connection
PC Communication
Cable (Straight)
2[m] FEB-1268-7
For connection via hub
7
Axis Link Cable 0.3[m] FEB-1635
8
Axis Link Terminator ---
FEB-1642
DDK Part #C30-AL2
9
Standard I/O Connector --- 10126-3000PE*
Included with discrete
I/O systems only
Standard I/O Cable 3[m] FEB-1634
• More information of connectors are found below in the cable detail
