Chapter 4 Installation and Wiring
PAGE 4-5
MFC-S120 Controller
Type Installation Weight
Internal
fan
MFC-S120
Two bell screw holes: M6 screw （ Upper part ）
Two elongated holes: M6 screw （ Lower part ）
3.70kg 2
【
【【
【 Caution 】
】】
】
Install the unit firmly with specified screws mentioned above to prevent the unit
from falling due to vibration (which could cause faulty operation)
