122 UMG70XV3-4EN 12.01.2009
13 Storing and Output of Measured Values
Fig. 13.3: Display of the received measuring data sets
Offline Output to a Terminal Program
• Select the program branch SPECIAL FUNCTION on the flowmeter. Press ENTER.
Select the list item PRINT MEAS.VAL. Press ENTER.
This error message will be displayed, if no measured
values are stored. Press ENTER.
Connect the flowmeter to a PC with a serial interface.
Press ENTER to transmit the stored measured values.
The display indicates that the measured values are be-
ing transmitted.
This error message will be displayed if an error has oc-
curred during the serial transmission. Press ENTER.
Check the connections and make sure that the PC is
ready to receive data.
The progress of the data transfer is displayed by a bar
graph.
Special Function
Print Meas.Val.
Send HEADER 01
................
SERIAL ERROR !
Print Meas.Val.
To Next Page
Loading...
