Flexim FLUXUS G704 User Manual

202 UMG70XV3-4EN 12.01.2009
A Technical Data
2 " Pipe Mounting Kit (option)
Terminal Assignment
JB01
T V T V S T G T G T R S T R V V S R S R
K L 2 K L 1
Transducers
terminal strip KL1
terminal connection
V signal
VS shield
RS shield
R signal
Extension Cable (Flowmeter)
terminal strip KL2
terminal connection
TV signal
TVS shield
TRS shield
TR signal
