Flexim FLUXUS G704 User Manual

UMG70XV3-4EN 12.01.2009 41
6 Installation of FLUXUS G704
Fig. 6.3: Transducers ATEX zone 1 - direct connection
Table 6.1: Terminal assignment
terminal connection
AV transducer (core)
AVS transducer (inner shield)
ARS transducer (inner shield)
AR transducer (core)
transducers
measuring channel B
cable gland
with double hole sealing
basic
part
transducers
ATEX zone 1
20 mm
70 mm
10 mm
transducer
cable
transducers
measuring channel A
equipotential bonding
terminal
(FLUXUS G704 A2)
compres-
sion part
cap nut
