UMG70XV3-4EN 12.01.2009 49
6 Installation of FLUXUS G704
Fig. 6.9: Transducers (ATEX zone 2, FM Div. 2, without explosion protection) -
connection via junction box, connection of extension cable and transducer cable
to the junction box
100 mm
75 mm
12 mm
transducers:
• ATEX zone 2
• FM Div. 2
• without explosion
protection
transducer
cable
extension cable
shield terminal
basic
part
compres-
sion part
cap nut
cable gland
TV TVS TG TG TRS TR
XV
XR
20 mm
