FT-111, User Manual Rev. 2.0.0, June 2022 Page 106 of 137
Figure 11.13 - GSDML Configuration
GSDML Configuration
Description
Input 2 word_1
1
st
Dword (FT-111 Output to PLC Input)
Input 2 word_2
2
nd
Dword (FT-111 Output to PLC Input)
Output 2 word_1
1
st
Dword (PLC Output to FT-111 Input)
Output 2 word_2
2
nd
Dword (PLC Output to FT-111 Input)
11.10.5 Profinet Data Structure
For the Data Structure see Appendix 1, page 118
